For years, our company has been producing suction cups of various forms, measures and different types of rubber (Para, Silicone, NBR etc...). Since this year we have decided to produce and e sell our suction cups also in the catalog.
| Item number | article description | A | B | C | D | E | F | H |
|---|---|---|---|---|---|---|---|---|
| VT9 | Suction cup D. 9 | 9 | 3 | 7.5 | 0.8 | 10 | ||
| VT9S | Suction cup D. 9 with bellows | 9 | 2.5 | 3 | 5 | 5.25 | 0.75 | 10 |
| VT14 | Suction cup D. 14 | 14 | 5 | 8 | 12 | 11.5 | 1.2 | 17.5 |
| VT14S | Suction cup D. 14 with bellows | 14 | 8 | 3.5 | 9 | 7.5 | 1.5 | 17 |
| VT15 | Suction cup D. 15 | 15 | 4 | 6 | 10 | 10 | 2.5 | 14 |
| VT17 | Suction cup D. 17 | 17 | 5 | 9 | 2 | 12.5 | ||
| VT17S | Suction cup D. 17 with bellows | 17 | 8 | 5 | 9 | 10.5 | 1.5 | 20 |
| VT18 | Suction cup D. 18 | 18 | 6 | 8 | 12 | 10 | 2.5 | 17.5 |
| VT19 | Suction cup D. 19 | 19 | 8 | 8 | 11 | 14.5 | 3 | 17.5 |
| VT25 | Suction cup D. 25 | 25 | 5 | 9 | 3.5 | 14.5 | ||
| VT25S | Suction cup D. 25 with bellows | 25 | 7.5 | 5 | 9 | 10.5 | 2.5 | 21.5 |
| VT28 | Suction cup D. 28 | 28 | 6 | 8 | 12 | 10 | 7.5 | 22.5 |
| VT38 | Suction cup D. 38 | 38 | 9 | 12 | 19 | 14 | 9 | 25 |
The suction cups in the catalog are available in stock But don't hesitate to contact us to find the solution tailored to yuor needs.
Producing molds on your own, We can offer customized solutions, at low cost, for your every need.
